Description:: Cobit is a robot car designed for STEAM education, open-source maker and DIY lover. It is driven by a stepper motor and can walk at precise distances. It integrates ultrasonic module, photosensitive sensor, led and RGB lights, missed buzzer, infrared receiving sensor, infrared line tracking sensor, and can be connected with Bluetooth module and ESP-01 wifi module. Compatible with arduino, micro-bit, esp wifi, can use C, C++, JavaScript, Python, Blocks language for programming, there are Lego mounting holes and IO ports on the car body, it can be extended to a writing robot, and it is also very convenient to connect various types of modules.It is suitable for use from 7 + children to college students and electronic fans.
SKU: CKK0008
Notice:: Has applied for patent protection.
- Introduction to products
- More introduction
- Compatible with arduino and microbit.
- It can write, draw and map.
- Can arduino C, C++, madecode graphical programming.
- It is compatible with LEGO and can be used for building block splicing.
- Integrated 1 buzzer, 4 GRB lights, 1 sonar,2 light detection, 2 infrared receivers, 2 line patrol functions.
- Reserved 3 analog ports, 2 digital ports, 1 IIC, 1 serial ports for external expansion experiment.
- Extend Bluetooth, ESP-01 WiFi and Servo motor functions.
- It can carry out accurate distance walking and Angle rotation.
- Use precise stepper motor to drive the car.
- Battery power can be monitored in real time.
- Mobile phone Bluetooth wireless control.
- Installation is very simple.
- wheels diameter is 65mm，Minimum rotation Angle is 0.9 degrees.
- Speed rating：0 = 0rpm，1 = 15rpm，2 = 30rpm，3 = 60rpm，4 = 120rpm
- The maximum measurement distance of sonar is 255CM with an accuracy of +/-1CM.
- Buzzer can be set frequency range: 20– 1K Hz.
- Single stepping wheel torque 110mN.m REF.
- 5A over current and short circuit protection.
- Distance between two wheels: 96mm .
- Based on Arduino Uno and Microbit .
- Open Arduino Uno and Microbit source code, source code is regularly updated.
- Size: 154*118mm
